Oven booth monitoring system OV-300
![](/img/2024/mon/k_mon_03_01.jpg)
OV-300 is a device that can monitor the interior of a high-temperature automobile painted oven booth from the outside.
It helps to prevent safety problems such as personnel accidents in advance by enabling image monitoring from outside without entering the hot oven booth.
- Monitor the oven booth from the outside by photographing the high temperature interior
- Air purge housing type cooling method and product lightweight design for safe operation in high temperature environments
- In the event of an abnormality in the booth, video monitoring can quickly identify the cause and take action to prevent serious failures
Applying LED lighting and installing large-capacity battery
![](/img/2024/mon/k_mon_03_02.jpg)
The OV-300 is equipped with a 20W LED lighting camera and a 12V high-capacity battery Even when the power is cut off, it accurately photographs the dark inside and deliver it to you.
High-definition image quality and wired/wireless monitoring system
![](/img/2024/mon/k_mon_03_03.jpg)
The OV-300 delivers high-definition image quality optimized for industrial sites Real-time monitoring on smartphones and tablet PCs through wired/wireless communication and It is possible to check the recorded video, making it easy to analyze the situation on the spot.
Composition items
Carrier Loaded Items | ||
1 | Camera | 1 |
2 | Tablet PC | 1 |
3 | Battery pack | 2(lithium ion 3S10P) |
4 | Compressor | 1 |
5 | Support rod | 1 set |
6 | Camera rod (assembled) | 1 set (Length 2M or More) |
7 | Air and control connection cables | 1 |
8 | Ethernet Gender and Cable | 1 set |
