RI-300
Measure wear and equipment abnormalities by recording images inside the conveyor rail at industrial sites
![](/img/2024/mon/k_mon_02_01.jpg)
![](/img/2024/mon/k_mon_02_02.jpg)
![](/img/2024/mon/k_mon_02_03.jpg)
Key Features
RI-300 is a video recording and measurement system that is mounted on the conveyor rail of the automation process to periodically inspect and measure the weariness of the rail in operation and the abnormality of the facility to prevent accidents.
![]() |
360 Degrees Laser Module Application |
![]() |
Check operation status through LED |
![]() |
5-WLED Near Field Lighting, 1-Status LED |
![]() |
Applying 10,000 mA lithium polymer BATTERY |
![]() |
Support for large-capacity video storage devices (Under 256GB SD Card, FAT3) |
![]() |
Secure last files with SuperCapacitor application |
![]() |
Adopting Sub u-COM for Power Management and MAIN CPU Failure Recovery |
![](/img/2024/mon/k_mon_02_11.jpg)
By linking the images recorded through the RI-300 with the rail wear measurement program, you can quickly and accurately check the degree of wear inside the rail, which is not visible to the naked eye.
![](/img/2024/mon/k_mon_02_12.jpg)
The RI-300 provides high-definition image quality optimized for industrial sites and facilitates field situation analysis by enabling real-time monitoring and checking recorded images on smartphones and tablet PCs through high-sensitivity WIFI.
Specification | ||
Sortation | ITEM | Specification |
CPU | Allwinner V3, ARM CortexTM-A7@1.2GHz | |
CAMERA | SENSOR | OmniVision OV4689, 4-Megapixel Camera Chip |
LENS | Aperture(Fixed Iris) : F#2.0, View Angle : D=148.9° | |
OPERATING Temp. | -30℃ ~ 85℃ | |
Video | CHANNEL | FHD/HD 1 Channel |
Compression method | H.264 | |
Resolution | FHD : 1920x1280, HD : 1280x720 | |
FRAME RATE | 15fps, 20fps, 25fps, 30fps | |
Recording Method | movement-sensing recording, impact-sensing recording, always recording | |
Sensor | Impact detection | Three axis sensor |
MEMORY | INTERNAL | Serial Flash 128M-BIT |
DDR3 2G-BIT | ||
Memory Card | SD 128GB, SD 256GB | |
Network | 2.4GHz WiFi | 802.11 n/g/b, 150Mbps, 2dBi External Antenna |
Other Specifications | Laser Module | 360-degree angel view red line laser module, DC3V~6V |
Operational status LED | BLUE light | |
BACKUP BATTERY | Super Capacitor 5.4V/ 3.3F | |
Power | 5V/10,000mA Lithium polymer | |
Electricity | 3.6W | |
Temperature/humidity | -20℃ ~ 80℃ / < 90% | |
Size (length x width x height) | 120(W)x299(D)x127(H)(WiFi with external antenna and laser module) |
