Industrial Robot Black Box RB-300
IO Interface
![](/img/2024/mon/k_mon_01_01.jpg)
The RB-300 also displays and records the robot's status on the video recording screen through the IO interface with the robot.
This allows us to more clearly determine the state of the robot (normal operation and ERROR occurrence) at the time of recording.
Various Monitoring Systems
![](/img/2024/mon/k_mon_01_02.jpg)
The RB-300 can be monitored in real time at any time through HDMI video transmission, and preview, VOD view, and file download are possible through high-sensitivity WIFI and Ethernet communication.
Image quality optimized for industrial sites
![](/img/2024/mon/k_mon_01_03.jpg)
Various quality tests provide high-definition full-HD and HD images optimized for industrial sites.
Applying LED lights
![](/img/2024/mon/k_mon_01_04.jpg)
In consideration of dark field conditions among various automation processes, LED lights are installed inside the product to accurately photograph and deliver dark internal conditions.
Various event recording modes
![](/img/2024/mon/k_mon_01_05.jpg)
motion detection, impact detection, IO event recording, Provides various recording modes such as regular recording
Specification | ||
Sortation | ITEM | Specification |
Camera Module | Image device | 4-Megapixel Camerachip sensor |
Lens | Fixed 120 degree angle of view (to support manual zoom in/out by adopting lens replacement method) | |
Lighting | 6-WLED or IRLED applicable | |
Record | CHANNEL | FULL HD/HD 1 Channel |
Compression method | H.264 | |
Resolution | 1920X1080p / 1280X720p | |
FRAME RATE | 30fps | |
Recording method | Motion detection/impact detection/ I/O Event/ Regular recording | |
Input/Output Interface | Video storage device | SD Card, Max. 512GB |
8-bit I/O Interface | 10-Pin DIN Connector Application | |
Networking | Protocol | TCP/IP Interface |
Ethernet | RJ45 | |
WIFI | 2.4Ghz WIFE, 802.11n/g/b,150Mbps,2dBi Antenna | |
INPUT POWER | DC 7V~36V | |
Power | 3W |
