AITZ 3D LASER SCAN VISION
빔모듈과 산업용 카메라를 이용한 구조광 방식의 초정밀급 3D스캔 비젼 센서
Identifying objects even in dark spaces and minimizing color impact
Can be customized for various processes such as height, slope, gap, shape measurement, etc
By measuring the width and height of the glass sealer, defects such as breakage and non-application are detected
AITZ LZ Measurement Case
AITZ LS Measurement Case
AITZ 3D laser Scan Vision 시야각
AITZ 3D Laser Scan Vision enables faster and more accurate performance through the development and application of its own algorithms.
| Width Distance | 200mm |
| FOV | 150mm |
| Measurement Depth | ±25mm |
| Width Distance | 100mm |
| FOV | 60x50(mm) |
| Measurement Depth | ±25mm |
AITZ 3D LASER SCAN SENSOR
※AITZ 3D Laser Scan Vision은 갭단차 측정 특허를 보유중이며, 알고리즘 특허출원을 진행중입니다.
| Specification | |
| Weight | 700g |
| Interface | Gigabit Ethernet |
| Power supply | 24V |
| Operating current | 1A(Max) |
| Width Distance | 200mm |
| FOV | 150mm |
| Measurement Depth | ±25mm |
| Repeating Precision | 0.01mm |
| Specification | |
| Weight | 1.2kg |
| Interface | Gigabit Ethernet |
| Power supply | 24V |
| Operating current | 1A(Max) |
| Width Distance | 100mm |
| FOV | 60X50(mm) |
| Measurement Depth | ±25mm |
| Repeating Precision | 0.01mm |
